Bushing, Spigot x Socket PVC Schedule 40 6" x 3/4" (437-524)
$20.27
The 437-524 is a PVC Schedule 40 reducing bushing with a spigot (male) inlet and socket (female) outlet, reducing from a 6" line down to a 3/4" branch or outlet. The spigot end inserts directly into any standard 6" Schedule 40 socket fitting or pipe hub, producing a solvent-welded, pressure-rated reduction in a single compact fitting — no additional adapter or coupling required.
Manufactured from rigid PVC compound conforming to ASTM D1784 cell classification requirements, this bushing is joined using standard PVC solvent cement and primer per ASTM D2564. Schedule 40 wall construction provides reliable performance in both pressure and gravity-flow piping systems, and the all-PVC material delivers excellent resistance to corrosion, chemicals, and biological fouling across a wide range of service environments.
The 437-524 is particularly well suited for large-diameter distribution manifolds, pump station assemblies, and irrigation mainlines where a 6" header must be tapped down to individual 3/4" service or zone connections. The bushing form factor keeps the transition compact and minimizes fitting count in congested mechanical or valve vault installations.
Specifications:
| Attribute | Detail |
|---|---|
| Part Number | 437-524 |
| Material | PVC (Polyvinyl Chloride) |
| Schedule / Class | Schedule 40 |
| Fitting Type | Reducing Bushing |
| End Connection | Spigot (Male) x Socket (Female) |
| Inlet Size | 6" |
| Outlet Size | 3/4" |
| Connection Method | Solvent Cement Weld |
| Pressure Rating | Rated per ASTM D2466 (temperature and size dependent) |
| Temperature Range | Up to 140°F (60°C) for pressure service |
| Color | White/Gray (PVC natural) |
| Standards | ASTM D2466, ASTM D1784 |
| Listing | NSF/ANSI 61 (potable water contact) |
Industries & Applications:
- Commercial Plumbing — Reducing large-diameter supply headers to individual 3/4" service branch connections in commercial buildings and facilities
- Municipal Water Systems — Service line reductions at pumping stations, treatment facilities, and distribution manifolds
- Industrial Process Piping — Diameter transitions in chemical handling, cooling water, and process fluid systems requiring corrosion-resistant materials
- Irrigation & Agriculture — Stepping down 6" mainline manifolds to 3/4" zone or lateral supply lines in large-scale irrigation systems
- HVAC & Mechanical — Chilled water and condenser water system branch transitions in commercial mechanical rooms
- Aquaculture & Water Treatment — Tank supply and drain manifold reductions using NSF-listed PVC materials
(No reviews yet)
Write a Review
Bushing, Spigot x Socket PVC Schedule 40 6" x 3/4" (437-524)
The 437-524 is a PVC Schedule 40 reducing bushing with a spigot (male) inlet and socket (female) outlet, reducing from a 6" line down to a 3/4" branch or outlet. The spigot end inserts directly into any standard 6" Schedule 40 socket fitting or pipe hub, producing a solvent-welded, pressure-rated reduction in a single compact fitting — no additional adapter or coupling required.
Manufactured from rigid PVC compound conforming to ASTM D1784 cell classification requirements, this bushing is joined using standard PVC solvent cement and primer per ASTM D2564. Schedule 40 wall construction provides reliable performance in both pressure and gravity-flow piping systems, and the all-PVC material delivers excellent resistance to corrosion, chemicals, and biological fouling across a wide range of service environments.
The 437-524 is particularly well suited for large-diameter distribution manifolds, pump station assemblies, and irrigation mainlines where a 6" header must be tapped down to individual 3/4" service or zone connections. The bushing form factor keeps the transition compact and minimizes fitting count in congested mechanical or valve vault installations.
Specifications:
| Attribute | Detail |
|---|---|
| Part Number | 437-524 |
| Material | PVC (Polyvinyl Chloride) |
| Schedule / Class | Schedule 40 |
| Fitting Type | Reducing Bushing |
| End Connection | Spigot (Male) x Socket (Female) |
| Inlet Size | 6" |
| Outlet Size | 3/4" |
| Connection Method | Solvent Cement Weld |
| Pressure Rating | Rated per ASTM D2466 (temperature and size dependent) |
| Temperature Range | Up to 140°F (60°C) for pressure service |
| Color | White/Gray (PVC natural) |
| Standards | ASTM D2466, ASTM D1784 |
| Listing | NSF/ANSI 61 (potable water contact) |
Industries & Applications:
- Commercial Plumbing — Reducing large-diameter supply headers to individual 3/4" service branch connections in commercial buildings and facilities
- Municipal Water Systems — Service line reductions at pumping stations, treatment facilities, and distribution manifolds
- Industrial Process Piping — Diameter transitions in chemical handling, cooling water, and process fluid systems requiring corrosion-resistant materials
- Irrigation & Agriculture — Stepping down 6" mainline manifolds to 3/4" zone or lateral supply lines in large-scale irrigation systems
- HVAC & Mechanical — Chilled water and condenser water system branch transitions in commercial mechanical rooms
- Aquaculture & Water Treatment — Tank supply and drain manifold reductions using NSF-listed PVC materials
- Part #:
- 437-524
- Product Family:
- Sch 40 PVC
- Carton Qty:
- 5
- Pallet Qty:
- 240
- Size:
- 6"
