Tee, Slip X Slip X FPT 12" x 12" x 2" (C602-662)

The C602-662 is a 12" x 2" Schedule 40 PVC reducing tee featuring slip socket connections on the 12" run and a 2" female pipe thread (FPT) branch outlet. This fitting is purpose-built for installations where a large-diameter solvent-weld main requires a permanent, in-line threaded branch connection — for a valve assembly, pressure gauge, air release, cleanout port, chemical injection point, or moderate-flow lateral — without the added complexity of a saddle fitting, tapping sleeve, or separate transition assembly.

The 2" FPT branch occupies the practical middle ground between a small instrument tap and a high-volume lateral takeoff. It is large enough to accept a full-port 2" ball valve, gate valve, or check valve for meaningful flow control, yet sized appropriately for monitoring connections, drain ports, bypass loops, and chemical dosing assemblies that do not require the full capacity of the 12" main. The female thread accepts Schedule 40 or Schedule 80 threaded nipples, valves, plugs, and reducers directly, giving installers flexibility in how the branch is configured or extended at the time of installation or in future system modifications.

The 12" slip sockets on the run bond with standard IPS-dimension Schedule 40 PVC pipe using heavy-bodied PVC solvent cement — the correct grade for large-diameter applications where socket depth, surface coverage, and cure time require a thicker-bodied cement than small-bore installations. Manufactured from virgin PVC compound to ASTM D2466, the C602-662 carries the white color standard for Schedule 40 fittings and is NSF/ANSI 61 listed for potable water service, qualifying it for municipal distribution, commercial water systems, and industrial process piping applications alike.

Specifications:

Industries & Applications:

• Municipal Water Distribution — Permanent in-line threaded tap on 12" water mains for air release valves, pressure monitoring connections, 2" blow-off assemblies, and service branch fittings without field tapping or saddle hardware
• Large-Scale Irrigation & Agriculture — Threaded branch connections on 12" irrigation supply headers for 2" zone valve stations, pressure regulators, fertigation injection points, and filter assemblies
• Industrial Process Piping — In-line valve and instrument connections on large-diameter process water, cooling water, and plant utility fluid mains where a permanent threaded branch fitting is preferred over field-installed saddle taps
• Water & Wastewater Treatment — Chemical dosing injection ports, sample collection taps, bypass connections, and monitoring instrument branches on 12" treatment plant headers and distribution mains
• Stormwater & Drainage Management — Threaded cleanout access, flow monitoring, or secondary outlet connections on 12" gravity-flow stormwater conveyance and detention system piping
• Fire Suppression & Site Utility — 2" branch valve, drain, or test connection off 12" underground fire protection supply mains on commercial, industrial, and campus-scale installations
• Aquaculture & Recirculating Systems — Threaded injection, return, or monitoring branch taps on large recirculating system headers for aeration feed lines, chemical treatment ports, or flow diversion assemblies
• Chemical Processing & Manufacturing — Corrosion-resistant in-line branch fittings on large-diameter chemical distribution or rinse water headers requiring a 2" threaded valve, plug, or monitoring connection
